SPECIFICATIONS	UNIT	A	B
INJECTION UNIT
Screw Dia	mm	40	45
Injection Pressure	kg/cm²	1980	1564
Injection Volume	cm³	213	270
Shot Weight PS	gram	190	243
Shot weight PE	gram	153	175
Screw Stroke	mm	170+5	170+5
Injection Rate	cm³/sec	139	176
Injection Speed	mm/sec	110	110
Plasticizing Capacity	kg/hr	65	77
Max. Screw Speed	rpm	350	350
L/D Ratio	-	20:01	18
Nozzle Contact Force	ton	3.5	3.5
Heater Capacity	kw	6	6
CLAMPING UNIT
Clamp Force	ton	125
Mold Opening Force	ton	6
Mold Opening Stroke	ton	540
Distance Bet.tie Bars	mm	455*425
Platen Dimensions WxH	mm	700*655
Maximum Day Light	mm	740
Minimum Mold Height	mm	200
Mold Closing Speed-Max	m/min	40
Mold Opening speed-Max	m/min	40
Ejector Force	ton	3
Ejector Stroke	mm	10
GENERAL
Pump Motor	kw	15
Oil Tank Capacity	Itr	250
Machine Dimension LxWxH	mm	4700x1300x2000
Machine Weight	ton	6.5
System Pressure	bar	165
